IVD Diagnostic
compatibility
Automatic calibration, test combination, effective time management of reagents, serum index, whole process detection, linear expansion of enzyme, blank deduction,dirty cuvette memory , cross infection prevention, patient information memory and association input, automatic report audit, data fuzzy query, report statistics and printing, reference range grading, alarm information classification, user operation privilege classification management.
Dedicated sampling probe equipped with sensitive liquid sensor, timely feedback of reagent & sample residuals
| Machine Type | Random access, open reagent & locked reagent (optional) |
| Test Speed | Constant 120 tests/hour (Mono reagent or double reagent) |
| Test Principle | Colorimetric method, turbidimetry |
| Test Method | 1 point end, 2 point end, Fixed-Time, Kinetics |
| Calibration Type | Linear & nonlinear |
| Mixing System | Mixer paddle-type mixing, effective reducing of carry-over. |
| Light Source | Halogen lamp |
| Wavelength | 340nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm, 700nm (4 more options) |
| Absorbance Range | 0–4.0 Abs |
| Resolution | 0.0001 Abs |
| Operating System | Windows XP, Windows 7, Windows 8, Windows 10 |
| Data Processing |
|
| Report Printing | 6 formats optional, support custom pattern |
| Interface | TCP/IP network interface |
| Power Supply | AC 110/220V ±10%, 50/60Hz, 1000VA |
| Water Consumption | 2.5L/hour (Maximum) |
| Dimensions | 750 × 535 × 475 mm (L × W × H) |
| Weight | 80 kg |
| Sample Tray | 40 sample positions |
| Sample Tube | Micro cup, test tube & blood collection tube can be used (Φ12–13 mm × 25–100 mm) |
| Sample Volume | 2–30 μL, step by 0.1 μL |
| Sample Probe | Liquid surface detection, timely tracking for liquid volume, collision avoidance. |
| Sample Barcode | Sample barcode reader (optional) |
| Reagent Tray | 80 reagent positions (40 for R1 & 40 for R2), non-stop cooling system with Peltier pad inside, 24-hour cooling at 2℃–14℃, open system supporting any reagent. |
| Reagent Volume | 20–300 μL, step by 1 μL |
| Reagent Needle | Liquid surface detection, timely tracking for liquid volume, collision avoidance. |
| Reagent Barcode | Reagent barcode reader (optional) |
| Reaction Tray | 50 reaction cuvettes, new amorphous optical plastic reaction cups with excellent transmittance. |
| Reaction Volume | 150–330 μL |
| Reaction Time | 10 minutes |
| Reaction Temperature | Peltier pad incubation system, 37℃ ±0.1℃ |
Contact our team for pricing and availability of the IVC-120A.
